Product description China's metal industry has found its best choice in the form of the 3015E fiber laser cutter. Renowned for its exceptional performance, this cutting-edge machine boasts a bed that is meticulously welded using a precise welding process, followed by annealing and aging...
China's metal industry has found its best choice in the form of the 3015E fiber laser cutter. Renowned for its exceptional performance, this cutting-edge machine boasts a bed that is meticulously welded using a precise welding process, followed by annealing and aging treatment for added strength and durability. The beam of the cutter is composed of airborne aluminium castings, ensuring superior quality. One of the standout features of this remarkable machine is its impressive running speed, which can reach an astounding 80 m/min. With all these exceptional attributes combined, it is clear why the 3015E fiber laser cutter has become the preferred option for customers in China's metal industry.
The fiber laser cutting machine configuration is designed to be standard and is perfectly suitable for 2000W power. To provide you with similar content by rearranging the given information, I would say: With a configuration tailored for optimal performance, the standard fiber laser cutting machine is an ideal choice for applications requiring a power capacity of 2000W.
Laser Source: MAX/RAYCUS 2000W
The cutting head used is BM111 from Raytools and it has an auto focus feature. I can provide more information about this cutting head if needed.
Control System: CYPCUT controller FS2000
The Yaskawa Y servo motor series from Japan offers high power output for various applications. With the Y: 1300W, X: 850W, and Z: 400W models, these motors provide excellent performance and reliability. Whether you need precise control in the Y-axis, robust power in the X-axis, or efficient operation in the Z-axis, the Yaskawa Y series has you covered. Made in Japan, these servo motors are known for their quality craftsmanship and advanced technology. Experience the power and precision of Yaskawa Y servo motors today.
Dual-temperature: S&A/Hanli cooling system;
Guide rail : PMI guide rail
Rack: APEX /YYC rack
Machine bed: Heat treated heavy sheet welding machine bed;
Gantry : Aluminium gantry
Reducer: MOTOVARIO reducer
Automatic lubrication system
Computer: Industry computer
Detail picture
Heavy-duty Welding Bed * The heavy-duty welding bed is welded with a thick rectangular tube with a diameter of 200*200mm. The bed weight can reach 1000kg. The bed body is annealed and milled by a large gantry to accurately drill all installation basic holes at once. * Higher tensile strength and dimensional stability. Effectively improve the accuracy of the bed, reduce the processing error of the workpiece. Increase the resistance and stability of the guide rail. * It reduces the loss of the equipment when it is used and keeps the precision of the machine for a long time and does not deform for 20 years. The equipment has good stability and reduces the processing errors caused by the vibration of the bed.
Aero-aluminum Integrated Beam * High precision. After manual aging, solution treatment and finishing, the beam has good integrity, rigidity, toughness and ductility. * Fast speed. Aluminum alloy has the features of lightweight and strong rigidity, which is conducive to high-speed movement during processing, and high flexibility is conducive to the high-speed cutting of various graphics on the basis of high precision. * High efficiency. The lighter weight beam can ensure the rapid operation of the equipment, improve the processing efficiency, and at the same time ensure the processing quality. Not only can the high-speed operation of the laser cutting machine be guaranteed, but also the accuracy and efficiency of the cutting processing. Effectively improve the service life and accuracy of the laser cutting machine, reduce time cost and reduce time loss. And after using the same time limit, the aluminum beam can ensure the cutting accuracy to the greatest extent, and at the same time, it can alleviate the kinetic energy of laser head during high-speed movement.
CYPUT CONTROL SYSTEM
*Support AI, DXF, PLT, Gerber, LXD and other graphic data formats, and accept the Cyput Laser Cutting Control System international standard G code generated by MaterCam, Type3, Wentai and other software.
*To conduct automatic optimization when opening/importing DXF and other external files, including: to remove repetitive lines, merger connected lines, remove tiny graphics as well as automatically distinguish inside and outside models and conduct sorting. The above each function can be defined, as well as be carried out manually. To support common editing and typesetting functions, including: zooming in and zooming out, translation, mirror, rotation, alignment, copying, combination and so on.
*To use the easiest way to set the lead, slotted compensation, micro connection, bridge-connection, lead inside or outside, lead seal without gap and so on.
GEARS, RACKS, GUIDES
*The guide rail and rack are calibrated by a precision collimator with an accuracy of ±0.02mm
*Using Taiwan APEX/YYC rack, grinding on all sides. And there is a positioning pin design to prevent the rack from shifting
*Using Taiwan HIWIN guide rail, and use oblique pressure block design to prevent displacement of guide rail
SWITZERLAND RAYTOOLS AUTO-FOCUS LASER CUTTING HEAD
*AUTOFOCUS: Through the built-in drive unit of the servo motor, the focusing lens is driven by the linear mechanism to automatically change the position in the focusing range. The user can set continuous zoom through the program to complete the rapid piercing of the thick plate and automatic cutting of different materials.
*EFFICIENT: Reading the saved cutting parameters through the operating system can quickly change the focus position of the laser head, eliminating manual operation and improving efficiency by 30%
*STABLE: Unique optical configuration, smooth and efficient airflow design and dual water-cooled design make the laser head work stably for a long time
OPTIONAL LASER SOURCE
*Different options of famous brand laser source(Reci/Raycus/IPG), We have professional sales and technician who can suggest you the most suitable laser source, depending your target price.
*Stable performance and high cost performance
*The fiber launch is stable, with long service life of nearly 100,000 hours
*It can run continuously 24 hours a day to meet the requirements of industrial continuous production
Our Services
(1)Two year quality guaranty, the machine with main parts (excluding the consumables) shall be changed free of charge when if any problem during the warranty period.
(2) Lifetime maintenance free of charge. (3) Free training course at our plant. (4) 24hours on line service each day, free technical support. (5) Machine has been adjusted before delivery. We will take machine photos and make machine working image for you, after gettingyour agreement, then we will book a ship. (6) Providing technical services to the door (We have professional engineers to offer machine installation commissioning and maintenance). (7) If you have any problem during your use.Our technicianwould help you to judge where the problem is and help you to solve it.
We can provide team viewer and skype with cam till all of your problems solved.
Sample display
Company Profile
Shandong Chaogong Laser Technology Co., Ltd. is one of the laser equipment manufacturers in Shandong Province, China. The company focuses on the R& D, manufacturing and sales of high-power laser processing equipment, including high-power laser cutting machine, laser welding machine and multi-functional laser processing equipment, to provide customers with personalized and professional laser processing system solutions. The main products of super laser cover the full power series of optical fiber laser cutting series, laser marking series, laser processing special equipment and cutting complete equipment, etc. the products are widely used in iron and steel metallurgy, non-ferrous metals, automobile and parts, aerospace, military electronics, precision instruments and meters, machinery manufacturing, hardware tools, integrated circuits, solar energy and other industries.
company's product service focuses on prevention, implements the customer return visit, continuous improvement, rapid response, efficient and accurate service mechanism to ensure the stable and efficient operation of products and help customers improve economic efficiency. The company has a complete sales and after-sales service network, marketing management center and domestic sales department, international trade department and customer service department. The sales and after-sales service network covers most cities in China, and the products are highly praised by customers.
company adheres to the business philosophy of "building brand with quality, pursuing development with science and technology, promoting step with innovation, and winning market with service". With advanced technology, the company is committed to providing global users with comprehensive laser application solutions. Chaogong is willing to work with all partners to make progress and win-win development and jointly build itself into a domestic manufacturing and R & D base for high-power laser processing complete equipment.
RFQ
Q1.how to get the most suitable machine and best price
please tell the material you want to working on?How to working on it ? Engraving ? Cutting ? Or other ?
What’s the MAX size of these material ?( length ? Width ? Thickness ?)
Then we will supply you 2-3 solution for advice.
Q2.What is the payment?
The payment is 30% or 50% T/T or Alibaba trade assurance in advance,the balance prior to the shipment.
Q3.What is the producing time after order?
The production time is about 10-20 days depend on the exact machine and the quantity.
Q4.If we don't know how to use the machine,can you teach us?
Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if you are busy ,we will
have the special engineer to your country,but you need to bear some fee,like tickets and hotel and meal.
Q5.How about your after-sales service?
we offer you 24 hours service phone,skype or what’sapp, our engineer also can go to door install or training.
Q6. Quality Control:
The whole production procedure will be under regular inspection and strict quality control. The
complete machine will be tested to make sure they can work very well before being out of factory.The testing video and pictures
will be sent to you before the delivery.
